ASTM B166 Inconel 601 UNS N06601 Round Bar and Rod

Short Description:

Inconel 601 (UNS N06601 / 2.4851) round bar and rod to ASTM B166 for oxidation-resistant and high-temperature service. Confirm diameter, length, condition, testing and material certification.

Grade: Inconel 601 / UNS N06601

Standard: ASTM B166 / ASME SB166

Product Form: Round Bar / Rod

Supply Condition: Solution Annealed

Send email to us Download as PDF

Product Detail

Product Tags

Inconel 601 round bar suppliers, Inconel 601 Flat Bar, Inconel 601 Hex Bar Suppliers in China, Inconel 601 Rod, Alloy 601 Hollow Bar Stockist in China, Inconel Alloy 601 Round Rod distributor, Inconel 601 round bar manufacturer in China.

The properties of Inconel 601 Round Bar make it a material of broad utility in such fields as thermal processing, chemical processing, pollution control, aerospace, and power generation. Inconel 601 Hexagonal Bar, Inconel 601 Hollow Bar and Inconel 601 Forged Bar exhibits good weldability and is readily joined by conventional welding products and processes. Inconel 601 Hex Bar, Inconel 601 Hex Rod and Alloy 601 Round Bar’s properties make it a material of broad utility in fields like thermal processing, chemical processing, pollution control, aerospace, and power generation.

Inconel 601 round bar Specification

Grade	Inconel 601 – UNS N06601
Specification	ASTM B166 UNS N06601
Inconel 601 Round bar size	Diameter: 3mm~800mm
Inconel 601 Angle bar size	3mm20mm20mm~12mm100mm100mm
Inconel 601 Square bar size	4mm4mm~100mm100mm
Inconel 601 Flat bar size	Thickness: 2mm~100mm
Inconel 601 Flat bar size	Width: 10mm~500mm
Inconel 601 Hex Bar size	2mm~100mm
Inconel 601 Billet Size	1/2″ to 495mm Diameter
Inconel 601 Rectangles Size	33mm x 30mm to 295mm x 1066mm
Inconel 601 Round Bar Standard Dimensions	As the customer request
Finish	Bright, Polish, Bright, Rough Turned, Grinding, Centreless Ground & Black
Tolerance	H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
Surface	Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline
Condition	Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished, Annealed round bar
Technique	Inconel 601 Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod
Inconel 601 Bar Type	Drawn Bar, Rolled Bar, Forged Bar, GFM Forged Bar, Open Die Bar, Forged Stepped Shafts, Forged Flat Bar, Forged Square Bar
Also Check price list of	Inconel Round Bar, Inconel 625 Round Bar, Inconel 718 Round Bar, Hastelloy Round Bar, Monel Round Bar, Titanium Round Bar, Copper Nickel Bar, Stainless Steel Round Bar
Form	Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc.
Our Inconel 601 round bar conforms to NACE MR0175/ISO 15156

Inconel 601 bar properties

ASTM B 166/ASME SB 166
DIN 17752
DIN 17753
DIN 17754
EN10095
ISO 9723
ISO 9724
ISO 9725

ASTM B166 Inconel 601 Bars Equivalent Grades:

STANDARD	WERKSTOFF NR.	UNS	GOST	AFNOR	JIS	BS	EN	OR
Inconel 601	2.4851	N06601	XH60BT	NC23FeA	NCF 601	NA 49	NiCr23Fe	ЭИ868

Inconel Alloy 601 Round, Bright, Hex, Threaded Bar Chemical Composition:

Grade	Ni	Cr	Fe	C	Mn	S	Si	Cu
Inconel 601	58.0 – 63.0	21.0 -25.0	Balance	0.10 max	1.0 max	0.015 max	0.5 max	1.0 max

Inconel Alloy 601 Round Bars Mechanical Properties:

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.1 g/cm3	1411 °C (2571 °F)	Psi – 80,000 , MPa – 550	Psi – 30,000 , MPa – 205	30 %

Physical Constants and Thermal Properties:

Property	Imperial Units	Metric Units
Density	0.293 lb/in³	8.11 g/cm³
Melting Range	2480 – 2571 °F	1360 – 1411 °C
Specific Heat	0.107 Btu/lb·°F	448 J/kg·°C
Curie Temperature	< -320 °F	< -196 °C
Permeability at 200 Oersted (15.9 kA/m)	1.003	–
Coefficient of Expansion (70–200°F / 20–100°C)	7.60 × 10⁻⁶ in/in·°F	13.75 µm/m·°C
Thermal Conductivity	78 Btu·in/ft²·h·°F	11.2 W/m·°C
Electrical Resistivity	717 ohm·circ mil/ft	1.19 µΩ·m
