Precision Soft Magnetic Alloy 1j79 Wire

Short Description:

Specifications of 1J79 magnetic wire: Grade 1J46, 1J50, 1J79, 1J85 Standard GB/T 15018-1994 Length 100 mm TO 6000 mm, customizable Diameter 10 mm To 100 mm or as per client requirement Types Filler Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire Surface Polished bright, Smooth Technology Cold Rolled, hot rolled CHEMICAL COMPOSITION OF Alloy 1J79 Wire: Grade Fe…

Grade:: 1J46, 1J50, 1J79, 1J85
Standard:: GB/T 15018-1994
Surface:: Bright,soft
Diameter:: 10 mm To 100 mm

Send email to us

Product Detail

Product Tags

Specifications of 1J79 magnetic wire:

Grade	1J46, 1J50, 1J79, 1J85
Standard	GB/T 15018-1994
Length	100 mm TO 6000 mm, customizable
Diameter	10 mm To 100 mm or as per client requirement
Types	Filler Wire, Coil Wire, Electrode Wire, Welding Wire, Wire mesh, Knitted wire mesh, filter mesh, mig wire, tig wire, spring wire
Surface	Polished bright, Smooth
Technology	Cold Rolled, hot rolled

CHEMICAL COMPOSITION OF Alloy 1J79 Wire:

Grade	Fe	Ni	Mn	Si	P	S	Cu	Mo
1J79	Rem	78.5-80.0	0.6-1.1	0.30-0.50	0.02	0.02	0.2	3.8-4.1

Applications of 1J79 Soft Magnetic Alloy Wire:

1.Transformers: The alloy is used in transformer cores to enhance efficiency and reduce energy losses due to its high magnetic permeability and low coercivity. 2.Inductors: In inductors, 1J79 helps achieve stable inductance values and minimizes core losses, improving performance in electronic circuits. 3.Magnetic Shielding: The alloy is utilized in magnetic shielding applications to protect sensitive electronic components from external magnetic fields. 4.Electromagnetic Devices: It is employed in various electromagnetic devices that require precise control of magnetic fields, such as relays and solenoids. 5.Sensors: The alloy is used in magnetic sensors for its reliable and consistent magnetic properties, which are crucial for accurate sensor readings. 6.Electronic Components: 1J79 is used in other electronic components that benefit from its soft magnetic characteristics, contributing to improved overall device performance. 7.High-Frequency Applications: Due to its low core losses and stable performance at high frequencies, the alloy is suitable for high-frequency applications such as RF transformers and high-frequency chokes.

SASA ALLOY'S Quality Assurance:

1. Visual Dimension Test 2. Mechanical examining like tensile, Elongation and reduction of area. 3. Impact analysis 4. Chemical examination analysis 5. Hardness test 6. Pitting protection test 7. Penetrant Test 8. Intergranular Corrosion Testing 9. Roughness Testing 10. Metallography Experimental Test
