Incoloy A286 Sheet Plate

Short Description:

Incoloy A286 sheet plates are known for their ability to maintain their mechanical properties at high temperatures, making them suitable for use in environments where extreme heat and stress are present.

Specification:ASTM A286 UNS S66286

Thickness:0.1mm to 100 mm Thk

Width:10-2500mm

Hardness:Soft, Hard, Half Hard, Quarter Hard


Product Detail

Product Tags

Sasa alloy supplies a comprehensive range in A286 Strip, A286 sheet and A286 plate products, catering for demands within a wide range of industries. We continue to invest in the latest laser cutting, water-jet cutting, shear, and plate saw cutting technology and inspection equipment to provide bespoke cut profiles from Incoloy A286 sheet and Incoloy A286 plate specific to your requirements. Sasa alloy produces high quality, straight-cut parts, compliant to customer specifications. All Incoloy A286 Coils cut pieces are deburred, marked and fully traceable. (cladding material) to either or both sides of a Incoloy A286 Clad Plate (base metal). There is a need, notably in utility flue gas desulfurization systems (scrubbers) for an economical, highly corrosive-resistant material. To complete this demand, Sasa alloy stock & supply Incoloy A286 Shim & Incoloy A286 thin-gauge clad steel plate.

A286 Plate Specification:
Alloy A286 Plate Specification ASTM A286 UNS S66286, ASME SA286, MSRR, AMS, BS
Alloy A286 Plate Sizes 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm
Alloy A286 Plate Thickness 0.1mm to 100 mm Thk
Alloy A286 Plate Width 10-2500mm
Alloy A286 Plate Length 2m, 2.44m, 3m, or as required
Alloy A286 Sheet ASTM ASTM A286
Alloy A286 Sheet AMS AMS 5525
Alloy A286 Plate Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Alloy A286 Sheet Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Alloy A286 Plate Stock in form of Alloy A286 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate
Material JIS: N0, N2, N1, NW2200, NW2201, NW4400, NW5500, NW6002, etc
DIN:H-Ni99.96, H-Ni99.95, H-Ni99.92, H-Ni99.90, H-Ni99.5, H-Ni99, etc
Alloy A286 Plate ASTM Standard ASTM A162, GB/T2054, DIN177502002, ASTM B127, ASTM B435, ASTM B582, ASTM B575, ASTM B168, ASTM B443, ASTM B463, ASTM B626, ASTM B536, etc
Alloy A286 Plate Dimensions  As the customer required
Why choose Hitesh Steel
  • EN 10204/3.1B,
  • Raw Materials Certificate
  • 100% Radiography Test Report
  • Third Party Inspection Report, etc
  • High special strength, high melt point
  • Excellent corrosive resistance,good thermal resistance
  • Customer support after-sales service
  • Huge Stock, Timely delivery
  • Strict Control from Raw Material to Finished A286 Plate
  • Free Quote, Inquiry answered within 24 hours
Alloy A286 profiling To provide a full profiling service we use numerous profiling methods including:

  • Laser Plate Cutting
  • Plasma Plate Cutting
  • Oxy-propane Flame Cutting
Specialized in
  • Alloy A286 Plate: material 3/16″ [5.00 mm] and over in thickness and over 10″ [250 mm] in width;
  • Alloy A286 Sheet: material under 3/16″ [5.00 mm] in thickness and 24″ [600 mm] and over in width;
  • Alloy A286 Strip: cold-rolled material under 3/16″ [5.00 mm] in thickness and under 24″ [600 mm] in width.
  • Alloy A286 Clad plate: Alloy A286 Clad plate is a composite steel plate made by bonding Alloy A286 plate, etc.



Type of incoloy A286 plates / sheets/coil:

Alloy 660 Sheets

Alloy 660 Plates

Alloy 660 Chequered Plate

  • •Incoloy A286 Sheets
  • •UNS S66286 Sheets
  • •ASTM A286 Incoloy A286 Sheets
  • •ASME SA286  Alloy A286 Sheets
  • •Incoloy A286 Plates
  • •UNS S66286 Plates
  • •ASTM A286 Incoloy A286 Plates
  • •ASME SA286  Alloy A286 Plates
  • •Incoloy A286 Chequered Plate
  • •UNS S66286 Chequered Plate
  • •ASTM A286 Incoloy A286 Chequered
  • •ASME SA286  Alloy A286 Chequered

Alloy 660 Rolls

Alloy 660 Shim Sheet Alloy 660 Perforated Sheet
  • •Incoloy A286 Rolls
  • •UNS S66286 Rolls
  • •ASTM A286 Incoloy A286 Rolls
  • •ASME SA286  Alloy A286 Rolls
  • •Incoloy A286 Shim Sheet
  • •UNS S66286 Shim Sheet
  • •ASTM A286 Incoloy A286 Shim Sheet
  • •ASME SA286  Alloy A286 Shim Sheet
  • •Incoloy A286 Perforated Sheet
  • •UNS S66286 Perforated Sheet
  • •ASTM A286 Incoloy A286 Perforated
  • •ASME SA286  Alloy A286 Perforated



Alloy A286 Sheet Stock:
STOCKED SIZES
SIZE Alloy A286 PLATE/ SHEET SIZE
.125″ Alloy A286 Plate, Alloy A286 Perforated Plate, Alloy A286 Sheet 3.18mm
.134″ Alloy A286 Coil, Alloy A286 Plate, Alloy A286 Strips 3.40mm
.156″ Alloy A286 Plate, Alloy A286 Perforated Plate, Alloy A286 Sheet 3.96mm
.187″ Alloy A286 Plate, Alloy A286 Sheet, Alloy A286 Rolling Plate 4.75mm
.250″ Alloy A286 Plate, Alloy A286 Rolling Sheets, Alloy A286 Sheet 6.35mm
.312″ Alloy A286 Plate, Alloy A286 Perforated Plate, Alloy A286 Sheet 7.92mm
.375″ Alloy A286 Plate, Alloy A286 Rolling Plate, Alloy A286 Sheet 9.53mm
.500″ Alloy A286 Plate, Alloy A286 Sheet, Alloy A286 Clad Plate 12.7mm
.625″ Alloy A286 Plate, Alloy A286 Flat Shim, Alloy A286 Sheet 15.9mm
.750″ Alloy A286 Plate, Alloy A286 Sheet, Alloy A286 Strips 19.1mm
.875″ Alloy A286 Plate, Alloy A286 Rolling Sheets, Alloy A286 Sheet 22.2mm
1″ Alloy A286 Plate, Alloy A286 Flat Shim, Alloy A286 Sheet 25.4mm
1.125″ Alloy A286 Plate, Alloy A286 Sheet, Alloy A286 Clad Plate 28.6mm
1.250″ Alloy A286 Plate, Alloy A286 Sheet, Alloy A286 Strips 31.8mm
1.500″ Alloy A286 Plate, Alloy A286 Rolling Plate, Alloy A286 Sheet 38.1mm
1.750″ Alloy A286 Plate, Alloy A286 Sheet, Alloy A286 Clad Plate 44.5mm
2″ Alloy A286 Plate, Alloy A286 Clad Plate, Alloy A286 Sheet 50.8mm
2.500″ Alloy A286 Plate, Alloy A286 Flat Shim, Alloy A286 Sheet 63.5mm
3″ Alloy A286 Plate, Alloy A286 Rolling Sheets, Alloy A286 Sheet 76.2mm



Incoloy Alloy A286 Sheet & Plate Equivalent Grades:
STANDARD WERKSTOFF NR. UNS
Incoloy Alloy A-286 1.4980 S66286



Incoloy Alloy A286 Sheet, Coil & Plate Chemical Composition:
Element Min Max
Al .35
B .003 .010
C - .08
Cr 13.5 16.0
Fe - Bal
Mn - .35
Mo 1.0 1.5
Ni 24.0 27.5
Si - .3
V .1 .5



Incoloy Alloy A286 Plate, Sheet & Coils Mechanical Properties
Property Value
Melting Range 2500-2600 °F
Poisson’s Ratio 0.306
.2% Yield Strength 112 ksi
Density .286 lb/inch³
Elongation 25 %
Hardness Max, Brinell 34
Ultimate Tensile Strength 171 ksi





Why Choose Us:

1. You can get the perfect material according to your requirement at the least possible price.
2. We also offer Reworks, FOB, CFR, CIF, and door to door delivery prices. We suggest you to do deal for shipping which will be quite economical.
3. The materials we provide are completely verifiable, right from raw material test certificate to the final dimensional statement.(Reports will show on requirement)
4. e guarantee to give a response within 24hours(usually in the same hour)
5. You can get stock alternatives, mill deliveries with minimizing manufacturing time.
6. We are fully dedicated to our customers. If it will not possible to meet your requirements after examining all options, we will not mislead you by making false promises which will create good customer relations.



Packing:

1. Packing is quite important especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put special concern regarding packaging.
2. Sasa alloy’s pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as,

IMG_1313_副本_副本  DSC09795_副本_副本  DSC09821_副本_副本
