GH3652 Bar – Nickel-Chromium-Cobalt High Temperature Alloy Bar
Product Description
GH3652 Bar is a nickel-chromium-cobalt high temperature alloy bar designed for applications requiring exceptional heat resistance, corrosion resistance, and mechanical stability at elevated temperatures. It is ideal for aerospace, power generation, chemical processing, and industrial machinery components. SASA ALLOY supplies GH3652 bars with full traceability, EN10204 3.1 certification, PMI testing, and dimensional inspection for project-ready delivery.
Product Parameters
| Item | Specification |
|---|---|
| Product Name | GH3652 Bar – Nickel-Chromium-Cobalt High Temperature Alloy Bar |
| Material Grade | GH3652 / Ni-Cr-Co Alloy / High Temperature Alloy |
| Product Form | Round Bar, Forged Bar, Machined Bar |
| Diameter | 6 mm – 300 mm or customized |
| Length | 500 mm – 6000 mm or cut to size |
| Surface | Hot Rolled / Forged / Peeled / Turned / Ground / Polished |
| Inspection | Chemical Analysis, Mechanical Testing, PMI Testing, Dimensional Inspection |
| Certificate | EN10204 3.1 Material Certificate available |
Chemical Composition
GH3652 Bar contains nickel, chromium, cobalt, iron, molybdenum, and other trace elements to provide excellent high-temperature performance and corrosion resistance. The table below provides typical composition ranges:
| Element | Content (%) |
|---|---|
| Nickel (Ni) | Balance |
| Chromium (Cr) | 15 – 20 |
| Cobalt (Co) | 35 – 40 |
| Iron (Fe) | ≤ 5 |
| Molybdenum (Mo) | 1 – 3 |
| Other | Trace |
Mechanical Properties
Mechanical properties of GH3652 Bar vary depending on diameter, forging, and heat treatment, providing high tensile strength, creep resistance, and stability at elevated temperatures.
| Property | Typical Value |
|---|---|
| Tensile Strength | 900 – 1200 MPa |
| Yield Strength | 600 – 800 MPa |
| Elongation | 15% min |
| Hardness | HRC 28 – 36 |
Common Size Table
| Diameter (mm) | Length (mm) | Surface |
|---|---|---|
| 6 – 20 | 500 – 3000 | Hot Rolled / Forged |
| 20 – 80 | 1000 – 6000 | Forged / Ground |
| 80 – 300 | 2000 – 6000 | Turned / Peeled |
Different Specifications Comparison
Comparison of GH3652 bar in different production forms:
- Hot Rolled Bar – Standard size, high-temperature applications
- Forged Bar – High strength, custom dimensions, aerospace and chemical processing
- Machined Bar – Precision components for turbines, heat exchangers, and petrochemical projects
Equivalent Standards and International Names
GH3652 is commonly referenced in China and Middle East projects as a nickel-chromium-cobalt high temperature alloy bar. International equivalents may include UNS N06625 or similar high-temperature nickel-based alloys.
Production Process Flow
- Raw Material Selection – Nickel, Chromium, Cobalt, Iron
- Melting and Casting – Controlled composition and solidification
- Forging / Hot Rolling – Shape and structural integrity
- Heat Treatment – Stress relief and high-temperature stability
- Turning / Peeling – Dimensional precision
- Surface Finishing – Polished, peeled, ground
- Inspection – PMI, chemical composition, mechanical testing
- Packing and Delivery – Traceable and project ready
Product Inspection
Chemical Composition
Verified via PMI testing and chemical analysis to meet GH3652 specification.
Mechanical Properties
Tensile strength, yield strength, elongation and hardness verified to ensure high-temperature performance.
Dimensional Inspection
Diameter, length and straightness checked before shipment.
Surface Inspection
Visual and dimensional inspection to ensure proper surface finish for aerospace, petrochemical, and industrial projects.
Product Packaging
Export-grade packaging with clear marking of grade, heat number, size, quantity, and customer PO number.
Applications
Used in aerospace components, high-temperature pipelines, heat exchangers, turbines, and petrochemical industrial equipment.
Why Choose SASA ALLOY?
- Professional supplier of GH3652 high-temperature alloy bars
- EN10204 3.1 certificate, PMI testing, UT inspection
- Material traceability with heat number control
- Custom diameter, length, surface finishing and machining available
FAQ
What is GH3652 Bar used for?
High temperature, corrosion resistant industrial components including turbines, heat exchangers, and petrochemical pipelines.
Is GH3652 suitable for aerospace?
Yes, GH3652 provides excellent high-temperature strength and oxidation resistance for aerospace components.
Contact Us
For GH3652 Bar and other nickel-chromium-cobalt high temperature alloy bars, contact SAKY ALLOY with required specifications, quantity, and inspection requirements.
