Inconel X-750 Round Bars, ASTM B637 Inconel X-750 Bright Bar, Incoloy UNS S07750 Hex Bars, Alloy X-750 Square Bars, Incoloy X-750 Flat Bars, Inconel UNS S07750 Forged Bars, Inconel Alloy X-750 Hot Rolled Bars Stockist & Exporter
| Inconel X-750 Round Bar Specifications: |
| Specifications |
ASTM B 637 / ASME SB 637, AMS 5669, AMS 5698, AMS 5699 |
| Dimensions |
ASTM, ASME and API |
| Size |
5 mm to 500 mm |
| Diameter |
0.1 mm to 100 mm |
| Grade |
Inconel X-750 – UNS N07750 |
| Finish |
Bright, Polish & Black |
| Length |
100 mm To 3000 mm Long & Above |
| Form |
Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Grade of Inconel X-750 Round Bar: |
| STANDARD |
WERKSTOFF NR. |
UNS |
| Inconel X-750 |
2.4669 |
N07750 |
| Chemical Composition of Inconel X-750 Round Bar: |
| Grade |
C |
Mn |
Si |
Cu |
S |
Al |
Ti |
Ni |
Cr |
| Inconel X-750 |
0.08 max |
1 max |
0.50 max |
0.50 max |
0.01 max |
0.40 – 1.0 |
2.25 – 2.75 |
70 min |
14 – 17 |
| Mechanical properties of Inconel X-750 Round Bar: |
| Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| 8.28 g/cm3 |
1430°C |
1267 MPa |
868 MPa |
25 % |
Incoloy DIN 2.4669 Round Bars, Inconel X-750 Cold Drawn Bars, Incoloy Alloy X-750 Rectangular Bars, ASTM B637 Alloy X-750 Black Bar, JIS / SUS Inconel X-750 Threaded Bars, X-750 Inconel Cold Finished Bars, Inconel X-750 Polished Round Bars Dealer & Wholesaler.
